Screw Compressor APS X 10 IVR Combi Dry G2 10 bar 10 HP/7.5 kW 380 - 1050 l/min 500 l

Name: Screw Compressor APS X 10 IVR Combi Dry G2 10 bar 10 HP/7.5 kW 380 - 1050 l/min 500 l
SKU: 369212-IVR-G2
Price: 9726.63 CHF
Availability: OutOfStock

Non Disponibile

SKU 369212-IVR-G2

Product details Product recommended Product documents Product reviews Product parts

Product details

SKU	369212-IVR-G2
EAN 13	8712418428513
Length (mm)	1902
Width (mm)	700
Height (mm)	1680
Weight (netto) (kg)	405,00
Units per product (pcs.)	1
Workload (labor/rest %)	100/0
Motor power (hp / kW)	10.0 HP / 7.5 kW
Motor efficiency class	IE4
Motor type	PM
Drive	Direct driven 1:1
Control panel	AirVision One
Available languages	French, English, Dutch, Polish, German, Spanish, Russian
Dryer	Yes
Air Receiver	Sì
Capacity air receiver (l)	500
Galvanized tank	No
Maximum pressure (bar)	10
Cut-in pressure (bar)	6

Free air delivery at 7 bar (l/min)	1050
Free air delivery at 8 bar (l/min)	1020
Free air delivery at 9.5 bar (l/min)	970
Minimum free air delivery (l/min)	380
Minimum free air delivery (m3/h)	22.8
Maximum free air delivery (l/min)	1050
Maximum free air delivery (m3/h)	63
Noise level dB (A) (0 m)	63
Noise level dB(A) (4 m)	43
Plug type	EU
Cooling air volume (m3/h)	3000
Main air connection (")	3/4
Oilfree	No
Oil capacity (l)	6
Stages	1
Start	Inverter
Voltage (V)	400 V / 50 Hz / 3 Ph
Variable speed (IVR)	Sì
Pump speed (rpm)	1220 - 2700
