Screw compressor EcoPower 30D IVR 13 bar 30 HP/22 kW 822 - 3924 l/min
16.163,71 CHF
Tasse incl.:
16.163,71 CHF
Tasse incl.:
Tasse incl.:
Non Disponibile
SKU
36678029-IVR
Product details
| SKU | 36678029-IVR |
|---|---|
| EAN 13 | 8712418424454 |
| Length (mm) | 1200 |
| Width (mm) | 835 |
| Height (mm) | 1220 |
| Weight (netto) (kg) | 370,00 |
| Units per product (pcs.) | 1 |
| Workload (labor/rest %) | 100/0 |
| Motor power (hp / kW) | 30.0 HP / 22.0 kW |
| Drive | Direct driven 1:1 |
| Control panel | ES 4000 STANDARD |
| Dryer | No |
| Air Receiver | No |
| Galvanized tank | No |
| Maximum pressure (bar) | 13 |
| Free air delivery at 7 bar (l/min) | 3924 |
| Free air delivery at 9.5 bar (l/min) | 3366 |
|---|---|
| Minimum free air delivery (l/min) | 822 |
| Minimum free air delivery (m3/h) | 49.3 |
| Maximum free air delivery (l/min) | 3924 |
| Maximum free air delivery (m3/h) | 235.6 |
| Noise level dB (A) (0 m) | 71 |
| Noise level dB(A) (4 m) | 51 |
| Plug type | EU |
| Maximum ambient temperature (°C) | 46 |
| Oilfree | No |
| Air-end | C67 |
| Start | Inverter |
| Voltage (V) | 400 V / 50 Hz / 3 Ph |
| IP classification | IP55 |
| Variable speed (IVR) | Sì |
